自動上料攪拌車的控制技術要求特點
1.各筒體，控制閥，電機按混凝土攪拌過程的要求運行，各筒體，控制閥，電機的控制必須準確，穩定，可靠。自上料混凝土攪拌車廠家它可裝運由攪拌廠（站）生產的混凝土或按配比混合的骨料（砂、石子）、水泥和水，在運輸過程中，不斷對濕料慢慢攪拌，防止混凝土在運輸過程中初凝和離析。
1. Each cylinder, control valve and motor shall operate according to the requirements of concrete mixing process. The control of each cylinder, control valve and motor must be accurate, stable and reliable. From the manufacturer of the loading concrete mixer truck, it can ship the concrete produced by the mixing plant (station) or the aggregate (sand, stone), cement and water mixed according to the proportion. During the transportation, the wet material is continuously mixed slowly to prevent the initial setting and segregation of the concrete during the transportation.
控制系統有自動和手動兩種工作方式，它們相互獨立，相互制約。
The control system has two working modes: automatic and manual, which are independent and restrict each other.
2.系統發展具有一個良好的抗干擾能力和完善的報警自保護管理功能；
2. The system development has a good anti-interference ability and perfect alarm self-protection management function;
3.通過與計算機通訊,可以進行顯示信息系統管理工作狀態、故障報警；
3. Through communication with the computer, it can display the working status and fault alarm of information system management;
一個工作周期內攪拌車主機系統少應清洗1次。每天可以生產活動結束后，則應對攪拌車主機信息進行比較的清洗，方法是：在清洗服務過程中，將水及少許石子放進攪拌主機內通過攪拌5～10min，清洗后將機內物料管理全部有效，不得有積水、積料;停機后再沖洗以及管道，攪拌罐內外環境灰塵和粘附的混凝土。
The mixer truck host system shall be cleaned at least once in a working cycle. After the daily production activities, the main engine information of the mixer truck shall be cleaned comprehensively. The method is: during the cleaning service, put water and a little stone into the mixer main engine and mix for 5 ~ 10min. After cleaning, all the material management in the mixer shall be effectively removed without ponding and accumulation; After shutdown, wash the and pipes to remove dust and adhered concrete inside and outside the mixing tank.
一般這種情況下，JS1000型攪拌設備主機之間加水約150～180kg左右，其他產品型號選擇主機可據此分析增減，也可自備高壓水槍或者進行數據清理。
Generally, in this case, about 150 ~ 180kg water is added between the main machines of JS1000 mixing equipment. The main machines of other product models can analyze the increase or decrease according to this, or provide their own high-pressure water gun or clean the data.
在沖洗攪拌主機料門時，應避免上部沖洗下的積料形成異物卡滯料門現象。攪拌過程中，若混凝土運輸車較長時間沒有到位(超過20～30min，尤其在夏季)，應加水對攪拌機進行簡易清洗。
When flushing the material door of the mixing machine, avoid the accumulation of material under the upper flushing to form the phenomenon of foreign matter blocking the material door. During mixing, if the concrete truck is not in place for a long time (more than 20 ~ 30min, especially in summer), add water to simply clean the mixer.
